Log Analytics

Switch between the Log List and the Log Analytics modes by clicking on the Log Mode button:

Log Analytics switch

Log Analytics query

Use the query to control what’s displayed in your Log Analytics:

  1. Choose a Measure or Facet to graph. Measure lets you choose the aggregation function whereas Facet displays the unique count.

    choose measure facet
  2. Select the aggregation function for the Measure you want to graph:

    aggregation function for Log Analytics
  3. Use Tag or Facet to split your graph.

    split by Log Analytics
  4. Choose to display either the X top or bottom values according to the selected measure.

    top bottom button
  5. Choose the Timesteps graph. Changing the global timeframe changes the list of available Timesteps values.

    Timestep

Visualizations

Select a Log Analytics visualization type using the graph selector:

Log Analytics selector

Available visualizations:

Timeseries

Visualize the evolution of a single measure (or a facet unique count of values) over a selected time frame, and (optionally) split by an available facet.

The following timeseries Log Analytics shows: The evolution of the top 5 URL Paths according to the number of unique Client IPs over the last month.

timeserie example

Top List

Visualize the top values from a facet according to the chosen measure:

The following Top List Log Analytics shows: The evolution of the top 5 URL Paths according to the number of unique Client IPs over the last month.

top list example

Select or click on a section of the graph to either zoom in the graph or see the list of logs corresponding to your selection:

view logs

Export

view logs button

Export your Log Analytics:

  • To create a new log monitor:
    Go to the Explorer view (not Analytics) and click Export. The query of your Log Analytics is used to create the log monitor query. This feature is not available from the Analytics view.
  • To an existing Timeboard:
    This functionality is in beta. Contact our support team to activate it for your organization.

Logs in Dashboard

This functionality is still in beta, contact our support team to activate it for your organization.

Export Log Analytics from the Log Explorer or build them directly in your Dashboard alongside metrics and traces.

Log Analytics in dashboard

Similar to the Log Explorer, click on a any graph in your dashboards to jump to the most related logs.
